Energy Diagnosis
Mechanical
facility works
Facilities system to maximize the efficiency of state-of-the-art cooling,
heating and sanitation facilities to create a pleasant living environment,
intelligent office buildings, social schools, hospitals, complex buildings, factories, etc
Advantage
- Avoid energy loss due to optimization of operation by facility
- Energy savings reduce environmental burden
- Stabilizing operational facilities by establishing an optimization model for energy operations
- Building data and information for self-saving activities
Criteria for diagnostic criteria
Grade | Annual Energy Use | Number of days taken | Required manpower | Total number of days and manpower |
||
---|---|---|---|---|---|---|
on-site diagnosis |
Creating a Report |
Summing up |
||||
A5 | 200,000TOE | 29 | 21 | 50 | 4 | 200 |
A4 | 10PTOE~200 TOE | 25 | 18 | 43 | 4 | 172 |
A3 | 50TOE~10PTOE | 21 | 15 | 36 | 4 | 144 |
A2 | 20,000TOE~50,000TOE | 17 | 12 | 29 | 4 | 116 |
A1 | 10,000TOE~20,000TOE | 14 | 9 | 23 | 4 | 92 |
B | 5,000TOE~10,000TOE | 11 | 8 | 19 | 3 | 57 |
C | Less than 5,000TOE | 8 | 5 | 13 | 3 | 39 |
Criteria for diagnosis in the building (public institution) sector
Sortation(Total floor area of buildings to be diagnosed) | Number of days taken | Required manpower | Total number of days and manpower |
|||
---|---|---|---|---|---|---|
on-site diagnosis |
Creating a Report |
Summing up |
Total | |||
It's 3,000m² to less than 10,000m² | 4 | 2 | 2 | 8 | 3 | 24 |
It's 10,000m² to less than 30,000m² | 5 | 2 | 3 | 10 | 4 | 40 |
It's 30,000m² to less than 60,000m² | 6 | 3 | 4 | 13 | 5 | 65 |
60,000m² | 7 | 4 | 4 | 15 | 6 | 90 |
Energy diagnostic cycle
- Public institutions should be diagnosed with a total floor area of 3,000 square meters or more, and if the reduction rate is more than 5% and
the investment recovery period is less than 10 years (Changho, 15 years of insulation), it should be improved to an ESCO project within two years from the end of the project - Companies with an annual energy use of more than 2,000 T must be diagnosed by the Energy Residual Agency every 5 years
- In the diagnosis cycle, it occurs due to the implementation of energy remnants, and the initial diagnosis period according to the mandatory requirement is assigned according to the allocation criteria
